ASTM A106 Seamless Pressure Pipe (also known as ASME SA106 pipe) is commonly used in the construction of oil and gas refineries, power plants, petrochemical plants, boilers, and ships where the piping must transport fluids and gases that exhibit higher temperatures and pressure levels.

Send Message

Introduction

ASTM A106 Seamless Pressure Pipe (also known as ASME SA106 pipe) is commonly used in the construction of oil and gas refineries, power plants, petrochemical plants, boilers, and ships where the piping must transport fluids and gases that exhibit higher temperatures and pressure levels.

TengLi steel stocks a full range of A106 pipe (SA106 Pipe) in:

Grades B and C

NPS ¼” to 30” diameter

Schedules 10 through 160, STD, XH and XXH

Schedules 20 through XXH

Wall Thickness beyond XXH, including:
● Up to 4” wall in 20” through 24” OD
● Up to 3” wall in 10” through 18” OD
● Up to 2” wall in 4” through 8” OD

Product Parameters

Grade A Grade B Grade C
Carbon max. % 0.25 0.30* 0.35*
*Manganese % 0.27 to 0.93 *0.29 to 1.06 *0.29 to 1.06
Phosphorous, max. % 0.035 0.035 0.035
Sulfur, max. % 0.035 0.035 0.035
Silicon, min.% 0.1 0.1 0.1
Chrome, max. % 0.4 0.4 0.4
Copper, max. % 0.4 0.4 0.4
Molybdenum, max. % 0.15 0.15 0.15
Nickel, max. % 0.4 0.4 0.4
Vanadium, max.% 0.08 0.08 0.08
*Unless otherwise specified by the purchaser, for each reduction of 0.01% below the specified carbon maximum, an increase of 0.06% manganese above the specified maximum will be permitted up to a maximum of 1.65% (1.35% for ASME SA106).
