Galvanizing is a zinc coating applied to sheets of steel through a process called “continuous hot-dip,” in which steel sheet passes through a bath of molten zinc. The liquid zinc bonds to the iron in the steel forming a protective layer on both sides of the sheet.

Send Message

Introduction

Galvanizing is a zinc coating applied to sheets of steel through a process called “continuous hot-dip,” in which steel sheet passes through a bath of molten zinc. The liquid zinc bonds to the iron in the steel forming a protective layer on both sides of the sheet.

Technical data

Product Name Galvanized Steel Plate
Grade Group DX51D, DX52D, DX53D, DX54D
Standard AISI, ASTM, BS, DIN, GB, JIS
Material ASTM/AISI/SGCC/CGCC/TDC51DZM/TDC52DTS350GD/TS550GD/
DX51D+Z Q195-q345
Thickness 0.12-2.0mm
Zinc Layer 20-120g/m2
Zinc Spangle Big, medium, small, zero
Width 600-1250mm
Coil ID 508/610mm
Grade Full hard/CS-A, B, C/FS-A/B/DQ/ SS-33, 37, 40, 50 and 80
Grades as per ASTM/EN/JIS/SASO
Coil Weight 1-8tons
Shape Coil, strip, flat,sheet, plate, etc
Application Building materials, steel structure, home construction, roofing
sheets, etc.
Surface Treatment Galvanized coated
Product Features Good performance, high precise, high straightness, high
evenness and surface finishing, uniform thickness, easy for
coating process, high tensile strength, high pressing property and low yield point
Package Standard exported packing
Port Any port in China
Delivery 7-15 working days
MOQ 1 ton
* minimum zinc coating mass of 45 gsm available for thickness above 0.60 mm thickness.
** 45 gsm (G15/Z45) will be available for export market only.
